3. Installation
2008-07 Instructions for Use for infinite® 200 No. 30017581 Rev. No. 1.4 53
Rear View
ATTENTION !
REMOVING OR BREAKING
THIS SEAL VOIDS YOUR
WARRANTY !
USB
INJECTOR
SN
REF
XXXXXXXXX
JJJJ-
3001605
INFINITE
AC 100-120 / 220- 240, 50/60
1 Instrument Fan
2 Power Supply Fan
3 Main Power Switch
4 Main Power Socket
5 Label – Technical Inspection Agency
6 Label – Options/Configuration
7 Name Plate
8 Warranty Label
9 USB Connection
10 Injector Connection
STOP
Caution
Only Tecan authorized service technicians are allowed to open the
instrument. Removing or breaking the warranty seal voids the warranty.
1
2
3
4
5
6
7
8
10
9
