Assembly
The radio transmitter is delivered with two pre-mounted
fastening clips for tightening the screw on the support
handles with a pipe diameter of up to mm.
• Loosen the screw connections on the universal clips.
Then attach the radio transmitter on the top or bottom
pipe (depending on the safety arm support) using these
two clips.
• Tighten up the screws after placing the radio transmitter
in its final position.
Depending on the required position of the transmitter, the
radio transmitter can be fitted on either safety arm support
(to the left or right of the toilet).
Programming the radio transmitter
Before being used for the first time, the radio transmitter
must first be assigned to the respective receiver (a com-
ponent of the corresponding flush system). There is a
corresponding button and LED on each receiver for this
purpose.
Programming the radio switch
• To assign the radio transmitter, press the programming
button on the receiver. This is visually acknowledged on
the receiver by the LED flashing once.
• Now, within seconds, press the flush-actuation sur-
face on the radio transmitter (see the illustration on the
right). If the LED flashes three times, this indicates that
the radio transmitter has been successfully programmed.
Flush function
After successful programming, you can now flush the toilet
by approaching the activation surface of the radio transmit-
ter (approx. - mm in front of the surface) or by touching
this surface. A successful flush signal is acknowledged by
an audible “beep”.
Technical data
Frequency 868.4 MHz
Addressing individual 32-bit address, programmable
on the receiver
Range max. 10 m
Functions Flushing for compatible toilet controls
Actuation capacitive switch, acoustic acknowledge-
ment by button sound
Power supply 3 V DC (2 x LR-1 alkaline batteries)
Battery life approx. 3 years or 100,000 flushes
Housing ABS housing approx. 85 x 46 16 mm
Assembly via clips on the safety arm support
Colour black (RAL 9005)
Degree of protection IP 54
Compatible toilet
controls
TECEplanus 9240354
TECEplanus 9240355
Geberit 115.867
Sanit 03.082.00.0000
Viega 462.376
Compatible radio electronics for TECE remote release
(. MHz) – safety arm support and radio transmitter
independent of arm support
Manufac-
turer
Item Item no.
AMS Radio release, can be mounted
on AMS safety arm support
DEUBAD Radio-controlled triggering DEU FK
Erlau FMI/E radio transmitter
FMI/O radio transmitter
Frelu Transmitter for wireless toilet
flush actuation
OP radio
FSB Radio-controlled switch
GEBERIT Hytronic switch ...
GROHE Radio transmitter
HEWI Toilet flush-actuation upgrade kit
(radio)
..., left
..., right
..
..L
..R
KEUCO Safety arm support with inte-
grated remote release
... mm right
... mm left
... mm right
... mm left
Lehnen Radio transmitter (with universal
clip)
Radio transmitter (white housing)
FA-
FA-
Normbau Radio transmitter NY.WCR ,
suitable for retrofitting
PBA Universal radio transmitter no known
Pressalit
Care
Radio transmitter, . MHz R
Wagner Universal radio transmitter
TECE flush plates – TECEplanus electronics, remote release
-
Flush plates
