TECElux Mini
The TECElux Mini is a real glass flush plate with electronic
flush actuation. A sensor recognizes when somebody
approaches the toilet – at which point, the contours of the
sensor surfaces light up through the seamlessly smooth
glass facing.
Flushing is activated without contact or by a light tap.
The safety glass plate only stands out slightly from the
wall. Thanks to the installation frame, it can also be flush-
mounted in the wall.
150
220
8
TECElux Mini toilet flush plate, dual-flush technology
Wall-mounted installation of the toilet flush
plate
1
Open the splash guard.
2
Open the corner valve and suciently flush out the pipe.
3
Turn the corner valve to close it again and connect the
reinforced hose to the filling valve. If you wish to fill the
cistern with water (e.g. for the initial operation), you must
open the corner valve again.
4
40
18
Ø 14
If there is no hole in the splash guard, drill a hole on the
splash guard in the area shown.
5a
Mount the actuation motor onto the splash guard.
