TECE Lux Mini - Insert Chute; Operating the Insert Chute

Insert chute
The TECE insert chute for cleaning tablets is characterised
by its high degree of universality, and can be combined
with all flush plates. Flush-mounted installation is also
possible.
In brick-wall structures, a wall structure of over  mm is
required. In dry-wall structures, the maximum wall structure
is  mm and in brick-wall structures,  mm.
To ensure this property, dierent installation steps must
be followed to combine the insert chute with TECE flush
plates. For this reason, dierent installation instructions are
provided with the insert chute. The application to which
the instructions refer is indicated in the top right-hand
corner on the first page of the respective instructions.
TECElux Mini instructions
Flush-mounted TECElux Mini instructions
TECEsquare, TECEloop, TECEplanus, TECEambia, TECEbase instructions
TECEsquare glass and flush-mounted TECEloop instructions
TECEsquare II metal and TECEnow instructions
Flush-mounted TECEnow instructions
Operating the insert chute
The metal spacing frame and guide rods are required for
installing the following flush plates:
TECElux
TECEsquare glass
TECEloop
TECEplanus
TECEambia
TECEbase
TECE flush plates – insert chute
-
Flush plates
