Technogym BIOSTRENGTH LINE - Disassembling the Solenoid

BIOSTRENGTH LINE: Service & Maintenance manual - rev. 2.1
Page 7.269
7.7.13. DISASSEMBLING THE SOLENOID
Figure 7.7.13-1
Follow the steps described in paragraph 7.7.7.
“Disassembling the rear Plexiglas weight stack
guard”.
1. Disconnect the connector a from the
SOLENOID cable.
2. Unscrew the 2 screws b using a 5-gauge
hexagonal T-wrench.
3. Remove the SOLENOID by lifting the
additional weight.
To reassemble the SOLENOID, follow the above
steps in reverse order.
