Technogym BIOSTRENGTH LINE - Disassembling the Seat Motor Brushes

BIOSTRENGTH LINE: Service & Maintenance manual - rev. 2.1
Page 7.378
7.9.31. DISASSEMBLING THE SEAT MOTOR BRUSHES
Figure 7.9.31-1
1. Shut off the equipment and unplug the power
cord from the wall socket.
2. Manually loosen the protective cover a of the
brush.
3. Remove the brush.
To reassemble the SEAT MOTOR BRUSHES,
follow the above steps in reverse order.
