Technogym BIOSTRENGTH LINE - Disassembling the Chest Rest Release Knob

BIOSTRENGTH LINE: Service & Maintenance manual - rev. 2.1
Page 7.337
7.8.34. DISASSEMBLING THE CHEST REST RELEASE KNOB
Figure 7.8.34-1
1. Shut off the equipment and unplug the power
cord from the wall socket.
2. Remove the peg a with a peg remover tool.
3. Turn the mobile part of the knob until you
see the 2 dowels under the 2 holes b.
4. Use a 2-gauge hexagonal T-wrench to
unscrew the 2 dowels.
5. Remove the CHEST REST RELEASE
KNOB by sliding it upward.
To reassemble the CHEST REST RELEASE
KNOB, follow the above steps in reverse order.
