3.5 RPM SENSOR BOARD
The optical RPM sensor board reads the speed of the ywheel, through the phonic wheel xed to
the ywheel.
The RPM board consists of only Hardware (no sw installed).
It provides the RPM signal to the watt sensor board.
Fig. 11
3.6 DISPLAY
3.6.1 DETAIL OF CONNECTORS
A
B
C
D
E
Fig. 12
