2.11 CABLES
The colour of the cables may change: in particular, refer to the Pin Out.
The cable 0WCU1364 is part of the Hall Sensor 0WCU1365. It is not a separate cable.
0WCU1422AAxx: GymKit Cable (*)
CPU Board
6x2 pin
Signal Colour
GymKit Board
12x1 pin
1 +5Vdc_NFC Red 1
2 dgnd (NFC) Black 8
3 rs232_NFC_TX Brown 2
4 rs232_NFC_RX White 3
5 - - -
6 - - -
7 rs232_NFC_VEN Yellow 4
8 rs232_NFC_IRQ Blue 5
9 NFC_SCL Grey 6
10 NFC_SDA Green 7
11 - - -
12 - - -
Tab. 9
(*): on the release date of the manual, It is not possible to connect Apple Watch to the Technogym
bike
0WCU1365xx: Watt Sensor Board Cable
Watt Sensor Board
3x1 pin
Signal Colour Hall Sensor
1 AD_In Brown to Hall Sensor
2 GND Black to Hall Sensor
3 VCC Red to Hall Sensor
Tab. 10
