8.8 DISASSEMBLING THE NOT PIVOTING DISPLAY
(OLD)
T
U
Remove the rear casing (T) and the
rear casing (U).
(TOOL: slotted screwdriver)
V
Disconnect the ground wire (V).
(TOOL: 2.5mm hexagon key wrench)
Pay attention to the route of the ground
cable.
