8. PROCEDURES FOR DISASSEMBLY-
REASSEMBLY AND REPLACEMENT OF
COMPONENTS
DANGER: Before disassembling, turn off the equipment (“O” state) and discon-
nect the power supply socket from the equipment / wall socket.
8.1 NECESSARY TOOLS
The tools required to carry out all the disassembling, adjustment and maintenance oper-
ations on the equipment are given in the TG SERVICE TOOLS BOX LIST, available on
Technogym Direct and during the training course on the e-learning platform.
8.2 EQUIPMENT REFERENCE
FRONT SIDE
REAR SIDE
RIGHT SIDE
LEFT SIDE
Fig. 54 - Equipment reference
TECHNOGYM BIKE LIVE Technical Service Guide
Rev. 2.0
- 63 -TSG-00187-EN - Uncontrolled copy if printed
