8.7 DISASSEMBLING THE DISPLAY GROUP

Remove the two screws (O). (TOOL:

5mm hexagon key wrench)

Remove the component (P).

TECHNOGYM BIKE LIVE Technical Service Guide

Rev. 2.0

- 73 -TSG-00187-EN - Uncontrolled copy if printed
