8.6 DISASSEMBLING THE RPM SENSOR BOARD

Remove the left side casing (F).

Disconnect the cable (G) from the RPM

sensor board.

TECHNOGYM BIKE LIVE Technical Service Guide

Rev. 2.0

- 69 -TSG-00187-EN - Uncontrolled copy if printed
