F
It’s now possible to remove the left cas-
ing (F).
There is no priority to be followed
in disassembling the right and left cas-
ings.
CAUTION: For safety reason,
when the main guards are re-
moved, turn the knob total-
ly clockwise to lock the y-
wheel and the mechanics of
the machine.
TECHNOGYM BIKE LIVE Technical Service Guide
Rev. 2.0
- 68 - TSG-00187-EN - Uncontrolled copy if printed
