D
Remove the three screws (D), on the
left side of equipment. (TOOL: key
wrench for Torx T25 head screw)
E
Remove the three screws (E), on the
left side of equipment. (TOOL: key
wrench for Torx T25 head screw)
Insert a cloth to protect the casing.
TECHNOGYM BIKE LIVE Technical Service Guide
Rev. 2.0
- 67 -TSG-00187-EN - Uncontrolled copy if printed
