5.3 UPDATE THE FW OF THE WATT SENSOR BOARD
The Equipment Software Loader (Firmware Wizard Section) enables you to update the FW of the
Watt Sensor Board.
For details, see the Equipment Software Loader User Manual, available on Technogym Direct.
To connect the Laptop (with Equipment Software Loader program already installed) to the Techn-
ogym Bike product, two cables are necessary:
A- Standard Cable also used for Group Cycle2 equipment (D92);
B- Adapter cable (the cable has two connectors that enable you to communicate with the Watts
Sensor Board, from the Display or from the Watt Sensor Board).
Fig. 22 - Adapter Cable
For details about the cables codes, see the Technogym Direct portal - iSP Parts Catalogue
section (GROUP CYCLE --> TECHNOGYM BIKE (D93)-->APPENDIX).
TECHNOGYM BIKE LIVE Technical Service Guide
Rev. 2.0
- 37 -TSG-00187-EN - Uncontrolled copy if printed
