Technogym D93TNL - Page 21

0WCU1068xx: RPM / Watt sensor Cable
Flying Con-
nect. n°7 to
Unity spiral
cable
3x2 pin
Signal Colour
Watt sensor
board
6x1 pin
RPM sen-
sor board
4x1 pin
1 Anode (VCC) Red 1 1
2 RX In (From Console) White 4
3 Cathode (GND) Black 2 2
4 Collector (Out Signal
RPM)
Yellow 5 4
5 Tx Out (To Console) Brown 3
6 - - - -
Tab. 11
0WCU1069xx: DIsplay power supply cable
Jack in +12Vdc Signal Colour Flying Connection
1 +12Vdc (Power) Red 2
2 GND (Power) Black 1
Tab. 12
0WCU1417xx: Display cable
Flying
Connec-
tion
2x2 pin
Flying
Connec-
tion
1x2 pin
Signal Colour
Display Unit
20x2 pin
Ground
Frame (eye-
let)
1 +Vdc_EXPIO (+5Vdc) Yellow 29
2 DGND Blue 31
3 RS232_TX_lowkit White 35
4 RS232_RX_lowkit Brown 37
1 GND Black Eyelet
10
9
8
7
