0WCU1417xx: Display cable
Flying
Connec-
tion
2x2 pin
Flying
Connec-
tion
1x2 pin
Signal Colour
Display Unit
20x2 pin
Ground
Frame (eye-
let)
2 +12Vdc Red 4
3
2
1
Tab. 13
0WCU1420xx: Spiral Cable / 0WCU1421xx for XL version
Display Side
Signal Colour
Low-Kit Side
Flying Con-
nect 1
2x2 pin
Flying Con-
nect 2
1x2 pin
Flying Con-
nect 3
3x2 pin
Flying Con-
nect 4
1x2 pin
1 5.5Vdc Red 1
2 GND Black 3
3 Rx In (From
Console)
White 2
4 Tx Out (To
console)
Brown 5
1 GND Black 1
2 12Vdc Red 2
Tab. 14
