B
Insert the hexagon key wrench in the
hole where there was the screw pre-
viously removed and lift the left brake
casing (B) by pulling outwards with
your ngers.
ATTENTION: DO NOT USE A
SCREWDRIVER AS, IN DO-
ING SO, YOU WILL DAMAGE
THE GUARD AND GASKET.
Same procedure to remove the
right brake casing.
