Technogym Run XT - Aligning the Elevation Bars

RUN XT: Service & Maintenance Manual - rev. 2.0
Page 8.7
8.6. ALIGNING THE ELEVATION BARS
Figure 8.6-1
1. With the machine turned over on one side,
turn one of the elevation bars until the wheel
shaft holes on both bars are aligned.
2. Use a gauge to make sure that both elevation
bars project by the same distance A from the
lead screw nuts. If this is not the case, turn
one of the bars by half a turn at a time and
repeat the measurement until perfect
alignment is obtained.
3. Reassemble the wheel shaft.
This procedure must be carried out
whenever the wheel shaft is reassembled.
