Technogym Run XT - Disassembling the up down Motor Brushes

RUN XT: Service & Maintenance Manual - rev. 2.0
Page 7.25
7.16. DISASSEMBLING THE UP-DOWN MOTOR BRUSHES
Figure 7.16-1
It is not possible to carry out this
procedure on all types of motors.
1. Carry out the procedures described in
paragraphs 7.7. “Disassembling the motor
guard” and 7.8. “Disassembling the front
plate”.
2. Manually, or using a small flat-head
screwdriver, unscrew the protective caps a of
the brushes.
3. Remove the BRUSHES b.
To reassemble the BRUSHES, carry out the
above steps in reverse order.
