RUN XT: Service & Maintenance Manual - rev. 2.0
Page 9.6
4. To save the modified value, press the FUNC key: the display reverts to showing the value of the
selected main function.
To display the parameters of the extended functions:
1. Press the FUNC key until function F 14 appears.
2. Press the 1 key to display the code of the extended function: for example the display will show 0
to indicate A 0. When the value . 0 appears it means that the type C extended functions are
available.
3. Press the FUNC key to access the extended function: the display will show A 0.
4. Press the 1 key once to view the value of the parameter: the display will show the value of the
parameter for the selected extended function.
5. To modify the value, press the 1 key to increase, or the 2 key to decrease.
6. To save the modified value, press the FUNC key: the display will revert to showing the value of
the selected extended function.
7. Press the FUNC key again to return to the main function menu.
Incorrect programming of the inverter may result in serious damage to the machine or
improper operation potentially hazardous for the user. Therefore, carry out this
operation only if certain of being able to perform the procedure correctly.
The tables below show the values of the function parameters, and indicate which of those parameters
take on a different value from the inverter default..
MAIN FUNCTIONS
FUNCTION Value Default
F 1 -
3
F 2 0.0
3
F 4 F
3
F 5 _ _
F 6 15
F 7 15
F 8 11
3
F 9 03
3
F 10 72
3
F 11 220
3
F 14 0
3
