RUN XT: Service & Maintenance Manual - rev. 2.0
Page 2.5
RX-11: Up-down motor power supply cable
Up-down board – Rectifier bridge
Up-down board Signal Color Rectifier bridge
CN6
1 48 Vac Red +
2 Ground Black
−
RX-12: Photocell cable
Up-down board – Photocell
Up-down
board / CN1
Signal Color Photocell
1 + 5 Vdc Red 1
2 Clock Orange 2
3 Direction Blue 3
4 ground Black 4
RX-8: Low voltage power supply cable
Power supply – Inverter interface board
Power supply/
CN2
Signal Color Inverter interf.
board / CN4
1 + 5 V Yellow 4
2-4-5 Ground Black 3
3 + 12 V Red 2
6 - 12 V Blue 1
The high voltage power supply cables and the ground connections are not described here, in that
they can be easily determined from the wiring diagram above.
