RUN XT: Service & Maintenance Manual - rev. 2.0
Page 2.7
RX-13 USA: Emergency cable
CPU – Emergency button – Safety switch reed relay
CPU/CN2 Signal Color Emergency
button
Safety
reed relay
1 NC contact Brown 1 -
- NC contact Blue 2 1
2 Reference Orange - 2
OBSERVE: An upgrade kit is available (code 0WK247) for installing the safety switch
on European machines.
The other cables are unchanged. Therefore, for their description, refer to the details provided for the
220 Model.
