RUN XT: Service & Maintenance Manual - rev. 2.0
Page 6.3
NO
YES
Do all DC voltages reach the
display?
Do all DC voltages reach the
inverter interface board?
Are all DC voltages present at
the output of the inverter
interface board?
Replace the display
CPU board: see
paragraph 7.3.
Replace cable RX-8
connecting the power
supply to the inverter
interface board
Replace the inverter
interface board: see
par. 7.12.
Replace cable RX-1
connecting the
*alternator interface
board to the display
YES
NO
NO
YES
NO
YES
3
4
5
Are DC voltages output by the
power supply correct?
2
Replace the power
supply: see paragraph
7.12.
YES
A
Continued on the following page.
