Is the up-down motor current
correct?
8
Lubricate the elevation
bars
NO
YES
B
Are the elevation bars lubricated?
Replace the up-down
motor: see paragraph
7.15.
NO
YES
Replace the photocell: see
paragraph 7.20.
NO
YES
Does the up-down board output the
status signal?
NO
Replace the up-down board: see
paragraph 7.12.
YES
Does the status signal reach the
CPU board?
NO
Check and/or replace cable RX-1
connecting the CPU board to the
up-down board
Replace the CPU board: see
paragraph 7.3.
YES
Is the pulse signal at the photocell
output correct?
9
10
11
