RUN XT: Service & Maintenance Manual - rev. 2.0
Page 7.9
Figure 7.6-3
5. Back off the 2 screws c which fix the
EMERGENCY BUTTON to the panel using
a large Phillips screwdriver.
Figure 7.6-4
6. Firmly gripping the inner part, push and
rotate the EMERGENCY BUTTON to
detach it.
To reassemble the EMERGENCY BUTTON,
carry out the above steps in reverse order.
For the 4-terminal version of the
emergency button, remember to connect
the wires in position 1-2 (NC button).
