RUN XT: Service & Maintenance Manual - rev. 2.0
Page 7.28
Figure 7.18-3
10. Remove the LEAD SCREW NUT GROUP.
To reassemble the LEAD SCREW NUT
GROUP, carry out the above steps in reverse
order.
