SELECTION LINE: Service & Maintenance Manual - rev. 4.0
Page 8.9
8.2. ROUTING OF THE WEIGHT STACK CABLE
The following pages illustrate the routing of the weight stack cables through the pulleys for each
machine, for use as reference when replacing the machine cables.
8.2.1. M810 – LEG CURL
M810 – LEG CURL
8.2.2. M812 / M912 – LAT MACHINE
M812 / M912 – LAT MACHINE
