SELECTION LINE: Service & Maintenance Manual - rev. 4.0

Page 4.9

4.1.6. POWER CONTROL DISPLAY INSTALLATION

Photo 4.1-21

1. Back off the 4 self-tapping screws fixing the

display, using a medium Phillips screwdriver.

Support the display before removing the

last screw.
