12. NECESSARY TOOLS
The following tools are necessary to carry out all disassembly, adjustment and maintenance
operations on the machines:
 Medium-sized Philips screwdriver;
 6.5-gauge wrench;
 8-gauge wrench;
 13-gauge wrench;
 14-gauge wrench;
 17-gauge wrench;
 22-gauge wrench;
 2.5-gauge hexagonal T-wrench;
 4-gauge hexagonal T-wrench;
 5-gauge hexagonal T-wrench;
 6-gauge hexagonal T-wrench (to use only for the floor fastening kit);
 8-gauge hexagonal T-wrench;
 14-gauge hexagonal T-wrench 14 (only for Leg Press bars and Abdominal and Lower Back foot
board);
 4-gauge hexagonal L-wrench;
 Special socket wrench provided by Technogym for Ø 17 ring-nut fitting ½ (code 0Y000061);
 Special socket wrench provided by Technogym for Ø 25 ring-nut fitting ½ (code 0Y000062);
 45-gauge hook wrench (only for side pin machines) (code 0Y000092);
 6-mm pointed tool;
 Torque wrench;
 Hammer;
 Drill;
 17mm spanner wrenches;
 5-mm – 4-mm – 2-mm Allen key;
 Flat screwdriver;
 Riveter.
CAUTION: Tool measurements are expressed in mm.
