JSDG2S Matching Motor
Motor
Specifications
dn-08 Displayed Value /
Cn030 Setting Value
Matching
Capacity
Motor Model
(The last code represents the
difference of encoder specifications)
Incremental type: 7 (17bit) / 3 (23bit)
Absolute type: 5 (15Bit)/ A (17bit)/ W
(23bit)
Power
(kW)
Speed
(rpm)
Encoder Specifications
(The last code represents the
difference of encoder specifications)
Incremental type: 7 (17bit) / C (23bit)
Absolute type: 5 (15Bit)/ A (17bit)/ D
(23bit)
75B
JSMA-PMH44B□ 4.4 1500 H250□
JSMA-PBH44B□ 4.4 1500 H252□
JSMA-PIH44B□ 4.4 1500 H257□
JSMA-PMH55B□ 5.5 1500 H251□
JSMA-PBH55B□ 5.5 1500 H253□
JSMA-PIH55B□ 5.5 1500 H258□
JSMA-PIH75B□ 7.5 1500 H259□
100B
JSMA-PBH44B□ 4.4 1500 H265□
JSMA-PBH55B□ 5.5 1500 H266□
JSMA-PIH55B□ 5.5 1500 H26B□
JSMA-PMH75B□ 7.5 1500 H261□
JSMA-PBH75B□ 7.5 1500 H267□
JSMA-PIH75B□ 7.5 1500 H269□
JSMA-PIH110B□-18 11 1500 H26A□
JSMA-PBD110B□ 11 4500 H26E□
1
50B
JSMA-PBH75B□ 7.5 1500 H271□
JSMA-PMH110B□ 11 1500 H272□
JSMA-PIH110B□-18 11 1500 H278□
JSMA-PIH110B□-22 11 1500 H27B□
JSMA-PBD110B□ 11 4500 H27C□
JSMA-PMH150B□ 15 1500 H273□
JSMA-PIH150B□ 15 1500 H27A□
200B
JSMA-PIH110B□-18 11 1500 H286□
JSMA-PMH150B□ 15 1500 H281□
JSMA-PIH150B□ 15 1500 H285□
