1-15
(5) JSDG2S-10A / 15A-L (200V class)
Heat sink and regenerative resistor
RS-485 communication connector
RS-485 communication connector
Screen cover
USB communication connector
Controller signal connector
Motor encoder connector
Fully closed loop encoder connector
Master power input connection terminal
External regenerative/internal
regenerative resistor connection terminal
Motor connection terminal
Ground FG connection terminal
