Tektronix MSO70000 Series Programmer's Manual

Command Groups
Command
Description
MARK:SELected:STATe Returns the on or off state of the selected
mark. The selected mark is at or near the
center of the d
isplay
MARK:SELect
ed:ZOOm:POSition?
Returns the p
osition of the selected mark, 0
to 100% of the zoom overview window
MARK:SELected:ZO Om :SC Ale? Returns the scale of the selected mark, 0 to
100% of the zoom overview window
MARK:TOTal?
Returns how many marks are currently in
use
SEARCH:SEARCH<x> Converts the specified search marks to the
user mark
s. <x> can be 1 to 8
SEARCH:S
EARCH<x>:COPy
Copies th
e search criteria to the trigger, the
trigger criteria to a search, or copy search to
search. <x> is the search number
SEARCH:SEARCH<x>:STATE Selects which search is selected
SEARCH:SEARCH<x>:TOTAL? Returns the total number of matches for the
search
. The total number of matches may
be more than the number of marks placed
SEARCH:SEARCH<x>:TRIGger:A:
DDRMemory:AUTOBitrate
Sets or queries the auto bit rate setting
SEARCH:SEARCH<x>:TRIGger:A:
DDRM
emory:AUTOReflevel
Sets or queries the auto reference levels
sett
ing
SEAR
CH:SEARCH<x>:TRIGger:A:
DDRMemory:BIT Rate
Sets
or queries the DDR memory bit rate
SEARCH:SEARCH<x>:TRIGger:A:
DDRMemory:CSActive
Sets or queries whether the expected
chip-select will be an active HIGH or LOW
SEARCH:SEARCH<x>:TRIGger:A:
DD
RMemory:CSLevel
Sets or queries the DDR memory search
ch
ip-select level
S
EARCH:SEARCH<x>:TRIGger:A:
DDRMemory:CSMode
S
ets or queries the chip-select mode
SEARCH:SEARCH<x>:TRIGger:A:
DDRMemory:CSSource
Sets or queries the chip select source
SEARCH:SEARCH<x>:TRIGger:A:
DDRMemory:DATASource
Sets or queries the DDR memory data
source
SEARCH:SEARCH<x>:TRIGger:A:
DDRMemory:HYSterisis
Sets or queries the hysterisis percent for
DDR memory searches
SEARCH:SEARCH<x>:TRIGger:A:
DDRMemory:REFLevel:DATA:HIGH
Sets or queries the value of the data HIGH
reference level
SEARCH:SEARCH<x>:TRIGger:A:
DDRMemory:REFLevel:DATA:LOW
Sets or queries the value of the data LOW
reference level
SEARCH:SEARCH<x>:TRIGger:A:
DDRMemory:REFLevel:DATA:MID
Sets or queries the value of the data MID
reference level
SEARCH:SEARCH<x>:TRIGger:A:
DDRMemory:REFLevel:STROBE:HIGH
Sets or queries the value of the strobe HIGH
reference level
2-46 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
