Tektronix MSO70000 Series Programmer's Manual

Command Groups
Command
Description
SEARCH:SEARCH<x>:TRIGger:A:
DDRMemory:REFLevel:STROBE:LOW
Sets or queries the value of the strobe LOW
reference level
SEARCH:SEARCH<x>:TRIGger:A:
DDRMemory:R
EFLevel:STROBE:MID
Sets or queries the value of the strobe MID
reference le
vel
SEARCH:SEA
RCH<x>:TRIGger:A:
DDRMemory:STANdard
Sets or quer
ies the DDR standard type for a
DDR Memory analysis search
SEARCH:SEARCH<x>:TRIGger:A:
DDRMemory:STROBEsource
Sets or queries the strobe source for a DDR
Memory analysis search
SEARCH:SEARCH<x>:TRIGger:A:EDG E:
SLOpe:CH
<x>
Sets or returns the slope for an edge trigger
search to
determine where to place a mark.
<x> is the search number or the channel
number
SEARCH:SEARCH<x>:TRIGger:A:EDG E:
SLOpe:M
ATH<x>
Sets or returns the slope for an edge trigger
search t
o determine where to place a mark.
<x> is the search number or the math
waveform number
SEARCH:SEARCH<x>:TRIGger:A:EDG E:
SLOpe:
REF<x>
Sets or returns the slope for an edge trigger
search
to determine where to place a mark.
<x> is the search number or the reference
waveform number
SEARCH:SEARCH<x>:TRIGger:A:EDG E:
SOUrc
e
Sets or returns the s ource waveform for an
edge t
rigger search to determine where to
place a mark. <x> is the search number
SEARCH:SEARCH<x>:TRIGger:A:GLItch:
POLarity:CH<x>
Sets or returns the polarity for a glitch trigger
search to determine where to place a mark.
<x> i
s the search number or channel number
SEA
RCH:SEARCH<x>:TRIG ger:A:G LItch:
POLarity:MATH<x>
Set
s or returns the polarity for a glitch trigger
search to determine where to place a mark.
<x> is the search number or math waveform
nu
mber
SE
ARCH:SEARCH<x>:TRIGger:A:GLItch:
POLarity:REF<x>
Se
ts or returns the polarity for a glitch trigger
search to determine where to place a mark.
<x> is the search number or reference
w
aveform number
S
EARCH:SEARC H<x>:T RIG ger:A:G LItch:
TRIGIF
S
ets or returns the accept or reject state for
a glitch trigger search to determine where to
place a mark. <x> is the search number
SEARCH:SEARCH<x>:TRIGger:A:GLItch:
WIDth
Sets or returns the glitch width for a glitch
trigger search to determine where to place a
mark. <x> is the search number
SEARCH:SEARCH<x>:TRIGger:A:LEVel:
CH<x>
Sets or returns the level for an edge trigger
search to determine where to place a
mark.
<x> is the search number or the
channel number. Each channel can have an
independent level
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-47
