Tektronix MSO70000 Series Programmer's Manual

Command Groups
Command
Description
SEARCH:SEARCH<x>:TRIGger:A:LEVel:
MATH<x>
Sets or returns the math waveform level for
an edge trigger search to determine where
to place a mark
. <x> is the search number
or math waveform number
SEARCH:SEARCH<x>:TRIGger:A:LEVel:
REF<x>
Sets or returns the specified reference
waveform level for a trigger search
to determin
ewheretoplaceamark.
SEARCH<x> is the search number and
REF<x> is the reference channel number
SEARCH:SEARCH<x>:TRIGger:A:LOGIc:
FUNCtion
Sets or returns the logic operator for a
pattern or
state trigger search to determine
where to place a mark. <x> is the search
number
SEARCH:SEARCH<x>:TRIGger:A:LOGIc:
INPut:CH
<x>
Sets or returns the Boolean logic criteria for
a pattern
or state trigger search to determine
wheretoplaceamark.
<x> is the search
number or the channel number
SEARCH:SEARCH<x>:TRIGger:A:LOGIc:
INPut:
MATH<x>
Sets or returns the Boolean logic criteria for
a patte
rn or state trigger search to determine
where to place a mark. <x> is the search
number or the math waveform number
SEARCH:SEARCH<x>:TRIGger:A:LOGIc:
INPut
:REF<x>
Sets or returns the Boolean logic criteria for
a patt
ern or state trigger search to determine
wheretoplaceamark.
<x> is the search
number or the reference channel number
SEARCH:SEARCH<x>:TRIGger:A:LOGIc:
THRe
shold:CH<x>
Sets or returns the channel threshold
leve
l for a pattern or state trigger search
to determine where to place a mark.
SEARCH<x> is the search number and
CH<x
>
is the channel number
SEA
RCH:SEARCH<x>:TRIGger:A:LOGIc:
THReshold:MATH<x>
Set
s or returns the math waveform threshold
level for a pattern or state trigger search to
determine where to place a mark. <x> is
the
search number or the Math waveform
number
SEARCH:SEARCH<x>:TRIGger:A:LOGIc:
THReshold:REF<x>
Sets or returns the reference waveform
threshold level for a pattern or state trigger
s
earch to determine where to place a mark.
<x> is the search number or the reference
waveform number
SEARCH:SEARCH<x>:TRIGger:A:PAT tern:
WHEn
Sets or queries the pattern trigger pattern
test that determines where to place a mark.
<x> is the search number
SEARCH:SEARCH<x>:TRIGger:A:PAT tern:
WHEn:LESSLimit
Sets or queries the time the pattern trigger
lesslimittestusesto determines where to
place a mark.
<x> is the search number
2-48 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
