Tektronix MSO70000 Series Programmer's Manual

Command Groups
Command
Description
SEARCH:SEARCH<x>:TRIGger:A:PATtern:
WHEn:MORELimit
Sets or queries the time the pattern trigger
more limit test uses to determines where to
place a mark.
<
x> is the s earch number
SEARCH:SEAR
CH<x>:TRIGger:A:PULs e:
SOUrce
Sets or retur
ns the source waveform for a
pulse trigger search to determine where to
place a mark. <x> is the search number.
This is the s
ource for Glitch, Width, Runt,
Timeout or Window searches.
SEARCH:SEARCH<x>:TRIGger:A:RUNT:
POLarity:CH<x>
Sets or returns the polarity setting for a runt
trigger search to determine where to place a
mark. <x> i
s the search number or channel
number
SEARCH:SEARCH<x>:TRIGger:A:RUNT:
POLarity:MATH<x>
Sets or returns the polarity setting for a runt
trigger search to determine where to place
amark.<x
> is the search number or math
waveform number
SEARCH:SEARCH<x>:TRIGger:A:RUNT:
POLarity:REF<x>
Sets or returns the polarity setting for a runt
trigger search to determine where to place a
mark. <
x> is the search number or r eference
waveform number
SEARCH:SEARCH<x>:TRIGger:A:RUNT:
THReshold:HIGH:CH<x>
Sets or returns the channel threshold HIGH
level for a runt trigger search to determine
where
to place a mark.
<x> is the search
number or the channel number
SEARCH:SEARCH<x>:TRIGger:A:RUNT:
THReshold:HIGH:MATH<x>
Sets or returns the math waveform threshold
HIGH level for a runt trigger search to
dete
rminewheretoplaceamark.
<x> is
the search number or the math w aveform
number
SEARCH:SEARCH<x>:TRIGger:A:RUNT:
THR
eshold:HIGH:REF<x>
Sets or returns the reference waveform
thr
eshold HIG H level for a runt trigger
search to determine where to place a mark.
<x> is the search number or the reference
wav
eform number
SE
ARCH:SEARCH<x>:TRIGger:A:RUNT:
THReshold:LOW:CH<x>
Se
ts or returns the channel threshold LO W
level for a runt trigger search to determine
wheretoplaceamark.
<x> is the search
n
umber or the channel number
S
EARCH:SEARCH<x>:TRIGger:A:RUNT:
THReshold:LOW:MATH<x>
S
ets or returns the math waveform threshold
LOW level for a runt trigger search to
determine where to place a mark.
<x> is
the search number or the math w aveform
number
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-49
