Tektronix TekScope THS710A User Manual

Functional Overview
THS710A, THS720A, THS730A & THS720P User Manual
2–5
3. MEASURE. Performs automated measurements of waveforms or
data logger display.
4. DISPLAY.
Changes appearance of waveform and display. Activates
harmonics (THS720P only).
Changes appearance of data logger display.
5. CURSOR. Activates scope or data logger cursors.
6. UTILITY. Activates system utility functions.
7. TRIGGER.
Activates trigger functions.
8. HORIZONTAL.
Changes horizontal characteristics of waveforms.
Adjusts scroll rate of data logger display.
9. VERTICAL.
Adjusts scale and position of waveform. Sets input parame-
ters.
Adjusts position of data logger display. Zooms data logger
display. Sets volts scale. Changes meter range. Changes vertical
scale.
