104



Appendix Raw Data Recording (RDR) SeaBat Sonar UI - User Manual

Step

Action

Click ‘Add’.

Click the arrow to change the Permission Level from ‘Read’ into

‘Read/Write’.

Click the ‘Share’ button to share the folder.
