Parameter Description
displays of different sizes.
l Bottom: Select to align displays at the bottom. With this setting,
use the bottom area of the screen when navigating between
displays of different sizes.
Vertical layout:
l Left: Select to align displays on the left. With this setting, use the
left area of the screen when navigating between displays of
different sizes.
l Center: Select to vertically center displays. With this setting, use
the center area of the screen when navigating between displays
of different sizes.
l Right: Select to align displays on the right. With this setting, use
the right area of the screen when navigating between displays of
different sizes.
Primary Configure which video port on the zero client you want as the primary
port.
Note: The display that is connected to the primary port becomes the
primary display (i.e., the display that contains the OSD menus before
you initiate a PCoIP session and the display that is requested for the
Windows taskbar after you initiate the session).
l Port 1: Select to configure port 1 on the zero client as the primary
port.
l Port 2: Select to configure port 2 on the zero client as the primary
port.
Position Specify which display is physically connected to each port.
Rotation Configure the rotation of the display in each port:
l No rotation
l 90° clockwise
l 180° rotation
l 90° counter-clockwise
Resolution The display resolution can be configured for a PCoIP session
between a virtual machine or host and a zero client. The zero client
detects the supported display resolutions of the monitor and
populates them to the drop-down menu. By default, the display’s
native resolution is used.
5.21.3 OSD Quad-display: Display Topology Settings
The Display Topology page lets users change the display topology for a PCoIP session. You
can access this page from the Options > User Settings > Display Topology menu on your
client OSD.
To apply the display topology feature to a PCoIP session between a client and a VMware
View virtual desktop, you must have VMware View 4.5 or later. To apply the display
TER1206003 Issue 1 263
PCoIP Zero Client and Host Administrator Guide
