Statistics Description
Image Quality The minimum and maximum quality setting is taken from the Image
page for the device.
The active setting is what’s currently being used in the session and
only appears on the host.
Image Quality
Preference
This setting is taken from the Image Quality Preference field on the
Image page. The value determines if the image is set to a smoother
versus a sharper image.
Build to Lossless Options that may appear in this field include the following:
Enabled: The Disable Build to Lossless field on the Image page is
unchecked.
Disabled: The Disable Build to Lossless field is checked.
Display The port number for the display.
Maximum Rate This column shows the refresh rate of the attached display.
If the Maximum Rate field on the Image page is set to 0 (i.e., there is
no limit), the maximum rate is taken from the monitor's refresh rate.
If the Maximum Rate field on the Image page is set to a value
greater than 0, the refresh rate shows as "User Defined."
Input Change Rate The rate of content change from the GPU. This includes everything
the user is doing (such as cursor movement, email editing, or
streaming video).
Note: This option is only available on the host. It does not appear on
the client.
Output Process Rate The frame rate currently being sent from the image engine on the
host to the client.
Image Quality Shows the current lossless state of the attached display:
l Lossy
l Perceptually lossless
l Lossless
Note: When you click the Reset Statistics button on a host Session Statistics or client
Session Statistics page, the statistics reported in the Home page are also reset.
3.10 AWI Menus
The AWI has five main menus that link to the various configuration and status pages.
l Configuration: The pages under this menu let you configure the various aspects for the
device, such as network settings, language, session parameters, etc.
l Permissions: The pages under this menu let you set up the permissions for the USB,
audio, and power on the client, and for the USB and audio on the host.
l Diagnostics: The pages under this menu help you troubleshoot the device.
TER1206003 Issue 1 35
PCoIP Zero Client and Host Administrator Guide
