6-15
Troubleshooting
DMS INTERFACE MODULEDMS INTERFACE MODULE
MessageMessage Meaning and Corrective ActionMeaning and Corrective Action
Check DMS Interface
Module-[SN] connection
M052
M054
Data cannot be sent to the DMS.
Check connections between the Core and Interface
Module and between the Interface Module and Data
Management System. Try a replacement Interface
Module. If the issue persists, contact Terumo
Cardiovascular Technical Support.
IN MEASUREMENT MODEIN MEASUREMENT MODE
MessageMessage Meaning and Corrective ActionMeaning and Corrective Action
Recalibration not
successful for:
[parameters]
Updates will not
be made for these
parameters.
The recalibration values are out of system range.
Conrm the parameters being measured are within
the operating range of the system prior to retrying
recalibration.
This may occur if you are using a BPM that has
not been calibrated or has gone longer than 24
hours since calibration. It may also indicate an error
with the Shunt Sensor, Cuvette or Probe hardware.
Contact Terumo Cardiovascular Technical Support.
Parameter values show
dashes (--)
Dashes are shown when parameter data is invalid.
Reasons for invalid data are:
• Values are outside the system display range
(including negative ow reading from CDI Flow
Sensors)
• H/S Probe is still connected to a color chip
• Required inputs are not available for calculation
Mark event unsuccessful
D505
A marked event could not be saved.
Retry marking the event. If the issue persists,
contact Terumo Cardiovascular Technical Support.
Storage full
D512
A screenshot could not be saved.
Retry taking a screenshot. If the issue persists,
contact Terumo Cardiovascular Technical Support.
