4 Transmitter
45
3. Select Channel x (e.g. "Channel 1") with  or  and confirm
selection with SET.
4. Select Max control or Min control with  or  (see graphic).
5. Press SET and edit Limit value as well as Hysteresis: Scroll
one digit to the right using  and increase value of digit by 1
using . Confirm with SET or abort entry with ESC.
6. Select Visual alarm with  or . Select YES or NO with  or
. Confirm with SET or abort entry with ESC.
7. Press SET and edit Alarm delay: Scroll one digit to the right
using  and increase value of digit by 1 using  (0 to 3600
seconds possible). Confirm with SET or abort entry with ESC.
8. Return to Channel x with ESC.
9. Return to Alarm x with ESC.
10. Change to the other relays using  or  and perform settings
in the same way.
Using alarm as collective alarm or not using it at all
If an alarm is assigned to the collective alarm, the relay is switched
and a visual alarm can be issued via the display as soon as (at
least) one of the warning or error messages of the testo 6383
transmitter (or the connected testo 6610 probe) becomes active.
The messages affecting the collective alarm can only be
selected in the P2A software, see 7.3. volume 2, Using the
software.
✓ Alarm is selected (see previous steps 1 and 2).
1. Use  or  to determine whether Alarm x should be used as a
Collective alarm or not used. Confirm selection with SET.
2. If collective alarm is selected: Select Visual alarm with  or .
Select YES or NO with  or . Confirm with SET and return to
Alarm x.
3. Change to another alarm using  or  and perform settings in
the same way.
4. Return to Main Menu Alarm with ESC.
5. Continue to Main Menu Settings with  or  or return to
Measuring Mode with ESC.
