Grey line: System error 6383 + probe, electronics 25 °C/+77 °F
Black line: System error 6383 + probe, electronics –25 to 70 °C/-13 to 158° F
6.2.5. testo 6615 trace humidity cable probe (self-
adjustment)
The testo 6615 probe corrects deviations in measurements by
means of self-adjustment. This has a particular significance with
low humidity values (in dewpoint range).
Also see 4.3.2.13. volume 1, Self adjustment of testo 6615
trace humidity probe, for the functional principle of the testo
6615.
Only use testo 6615 with sintered P
TFE protection cap (art.
no. 0554 0759) or sintered stainless steel protection cap
(art. no. 0554 0647).
During the self-adjustment phase the signal values of the
analog
outputs remain on hold, meaning they are frozen for
the duration.
At a glance
1
Connector
2
Key
3
Probe cable
4
Probe shaft
5
Protection cap
(including: humidity
and temperature
sensor)
