6 testo 6610 probes
86
Reproducibility
• ± 0.2 % RH better
Sensor
• Response time without protective filter: t 90 max. 15 sec.
Probe dimensions
• Diameter of probe shaft: 12 mm
• Diameter of temp. probe: 3 mm
• L = approx. 200/500 mm
• L – A = 165/465 mm
• A see Overview of probe and filter types, page 74.
Probe length incl. probe shaft and filter
• 1/2/5/10 m
Pressure resistance**
• PN 10 (probe tip)
• PN 1 (if end of probe/cable is involved in process)
** If installing probe under pressure, please use cutting ring screw
connection (order no. 0554 1795).
Measuring accuracy of heated testo 6614 cable probe
Humidity error, absolute |±% RH| as a factor of process humidity
(% RH)
Temperature error as a factor of process temperature and
temperature of electronics
