TESTO 6383 - Editing Main Menu Analysis

4 Transmitter
48
2. Select H202 weight prop. with  or , confirm selection with
SET or cancel with ESC.
The selection H
2
O
2
passively vaporized or H
2
O
2
actively
vaporized in the submenu describes whether H
2
O
2
is
generated by means of evaporation or is actively vaporized in
the process.
3. Select H
2
O
2
passively vaporized or H
2
O
2
actively vaporized
with  or  and confirm with SET.
4. Edit proportion by weight of the H
2
O
2
in % (% H
2
O
2
proportion
by weight in the liquid initial solution): Scroll one digit to the right
using  and increase value of digit by 1 using . Confirm with
SET or abort entry with ESC.
5. Return to H202 weight prop. with ESC and use or  to
continue to Humidity process pressure.
6. Select Humidity process pressure with  or  and confirm
selection with SET.
7. Edit humidity process pressure: Scroll one digit to the right
using  and increase value of digit by 1 using . Confirm with
SET or abort entry with ESC.
8. Return to Change parameters with ESC.
9. Return to Main Menu Settings with ESC.
4.4.5.6. Editing Main Menu Analysis
You can test the functionality of analog and relay outputs. In
addition, you can read off the minimum and maximum values (since
the last voltage supply or reset of the min./max. values).
Testing functionality of analog outputs
This function affects the analog outputs directly, not only
the test contacts.
1. In the Measuring Mode press SET, select main menu Analysis
with  or  and confirm selection with SET.
- Test Analog Output is shown.
2. Press SET and choose between Analog output 1, 2, 3 with 
or .
3. Press SET, scroll one digit to the right using  and increase
value of digit by 1 using . Any analog output value can be
predefined, e.g. for an analog output of 4 to 20 mA, the value
"6.0 mA". Confirm with SET or abort entry with ESC.
4. Accept setting by pressing SET and test with multimeter
(minimum requirement: resolution 6.5 digits, at least 2-times
more accurate than the 6383) as follows:
