TESTO 6383 - Page 9

4 Transmitter
9
Pressure
measuring range
depending on
version ordered
Resolution Overload
-500 to 500 Pa 0.1 Pa 20,000 Pa
-10 to 10 hPa
0.01 hPa
200 hPa
Upon delivery and following a factory reset the readings are
shown in the display in the unit that was ordered via the
KMAT option Fxx, see
Ordering options for testo 6383 transmitter (0555 6383),
8.2.1, volume 2.
Humidity and temperature resolution
• 0.1 % RH or 0.01 °C/0.01 °F
Meas. cycle
• 1/sec
Interface
• Mini-DIN for P2A software (parameterizing and adjusting
software) and handheld testo 400/650
• optional: Ethernet interface
Voltage supply
• 4-wire (separate signal and supply lines): 20 to 30 V AC/DC,
300 mA power consumption
Maximum load
• 4-wire: 500 Ω (power output)
