TESTO Saveris Series User Manual

8 Technical data
107
8.3.6 testo Saveris T4E
4-channel Ethernet data logger with 4 external TC probe connections.
Feature Value
Probe type
TC
Measuring range
TC type S
TC type T
TC type J
TC type K
0 to +1760°C
-200 to +400°C
-100 to +750°C
-195 to +1350°C
Accuracy
±0.5°C or 0.5% of measured value
Resolution
0.1°C / TC type S 1°C
Connection Mini-DIN service interface is accessible
externally
4 x TCs via TC socket
max. difference in potential 50 V
Weight
Approx. 220 g
The technical data refer to the data logger in a stable, stationary
operating mode. To obtain a stable measurement, the data logger must
have been in operation for one to two hours.
The use of isolated thermocouples is recommended for supplying the
Ethernet data logger. Otherwise discrepancies in readings of up to
0.6°C may occur due to leakage flows.
8.3.7 testo Saveris H2E
Humidity Ethernet data logger 2%
Feature Value
Probe type
Humidity sensor
NTC
Measuring range
0 to 100% RH
10
-20 to +70°C
10
Not for condensing atmospheres. For constant use in high humidity (>80%
RH at ≤30°C for >12 h, >60% RH at >30°C for >12 h), please contact us at
www.testo.com

TESTO Saveris Series Specifications

General

Measurement Parameters	Temperature, Humidity, CO2, Pressure, Differential Pressure
Humidity Range	0 to 100 %RH
CO2 Range	0 to 5000 ppm
Communication	Ethernet, WiFi, USB
Data Storage	Internal memory
Alarm	Visual and audible alarms
Power Supply	Battery, Mains power
Software	Testo Saveris software
