TESTO Saveris Series User Manual

6 Commissioning
58
7
Briefly press the Connect key on the rear of the Saveris router.

If the LED on the front of the router flashes
• green, there is a radio link to the Saveris base.
• red, there is no radio link to the Saveris base.
8
Briefly press the Connect key on the rear of the data logger.

If the LED on the front of the data logger flashes
• green, there is a radio link to the Saveris router.
• red, there is no radio link to the Saveris router.
If there is no radio link even after changing the location of the data
logger and/or Saveris router, use a Saveris converter; see section 6.9.6
Integrating Saveris converter (optional).
If you want to use data loggers within a router cascade, see section
6.9.5.5 Connecting Saveris routers in series.
6.9.5.5 Connecting Saveris routers in series
In each case, a maximum of three Saveris routers can be connected in
series, “cascaded”.
The measurement data of up to five Saveris radio data loggers can be
transmitted to the Saveris base per router cascade. The five Saveris
radio data loggers can be connected to any Saveris router in the
cascade.
A Saveris converter can be connected upstream of the router cascade.

All Saveris routers are connected to the power supply and registered on
the Saveris base.
1
Under Start | All programs | Testo, click on Testo Saveris startup
wizard.

TESTO Saveris Series Specifications

General

Measurement Parameters	Temperature, Humidity, CO2, Pressure, Differential Pressure
Humidity Range	0 to 100 %RH
CO2 Range	0 to 5000 ppm
Communication	Ethernet, WiFi, USB
Data Storage	Internal memory
Alarm	Visual and audible alarms
Power Supply	Battery, Mains power
Software	Testo Saveris software
