TESTO Saveris Series User Manual

6 Commissioning
57

The welcome dialogue for the startup
wizard is displayed.
2
Click on [Next >].

The System status dialogue is displayed with the General tab.
3
Switch to the Integrate router tab.
The direct connection type means that the data logger is directly
registered on the Saveris base or a Saveris converter.
4
Click in the Connection type cell of the data logger which needs to be
assigned to a Saveris router.

The cell is shown as a selection list.
5
Use the button to open the selection list and select the Saveris router
which the data logger needs to be assigned to.
5.1
Perform steps 4 to 5 for all other data loggers with measurement data
that need to be transmitted to the Saveris base via a Saveris router.
6
Position the data logger and Saveris router at their mounting locations
to check the radio links.

TESTO Saveris Series Specifications

General

Measurement Parameters	Temperature, Humidity, CO2, Pressure, Differential Pressure
Humidity Range	0 to 100 %RH
CO2 Range	0 to 5000 ppm
Communication	Ethernet, WiFi, USB
Data Storage	Internal memory
Alarm	Visual and audible alarms
Power Supply	Battery, Mains power
Software	Testo Saveris software
